Brand: PRO-FORM
Category: Treadmill
Manual Type:
Language:
Manual for CROSSWALK 405 E - Troubleshooting and error codes + PDF Download
Uploaded: April 8, 2025, 1:57 p.m.
Manual Publish Date: 2006-01-01
Warranty Summary
This treadmill has a 90-day full warranty for defects in material or workmanship and a 3-year warranty for the drive motor from the date of purchase.
- Plug in the power cord and ensure the circuit breaker is reset.
- Stand on the foot rails, attach the safety clip, and insert the key into the console.
- Start the treadmill by pressing 'Start', 'Speed increase', or a numbered button.
- Adjust speed and incline as needed during your workout.
- Monitor your progress on the console displays.
- Stop the treadmill by pressing the 'Stop' button.
- Remove the key and unplug the power cord after use.
Troubleshooting and error codes
| Problem | Solution |
|---|---|
| The power does not turn on | a. Check power cord, surge suppressor, and outlet. b. Ensure key is inserted in the console. c. Reset the circuit breaker. |
| The power turns off during use | a. Check and reset circuit breaker. b. Ensure power cord is plugged in. c. Reinsert the key. |
| The displays of the console do not function properly | a. Reconnect reed switch and magnet by adjusting their gap (approx. 1/8"). |
| The walking belt slows when walked on | a. Use a single-outlet surge suppressor. b. Adjust rear roller bolts to tighten walking belt. |
| The walking belt is off-center or slips when walked on | a. Adjust rear roller bolts to center walking belt. b. Adjust rear roller bolts to tighten walking belt. |
| The upper body arms squeak during use | a. Apply white marine grease to the resistance cone. |
Troubleshooting and error codes
| Problem | Solution |
|---|---|
| The power does not turn on | a. Check power cord, surge suppressor, and outlet. b. Ensure key is inserted in the console. c. Reset the circuit breaker. |
| The power turns off during use | a. Check and reset circuit breaker. b. Ensure power cord is plugged in. c. Reinsert the key. |
| The displays of the console do not function properly | a. Reconnect reed switch and magnet by adjusting their gap (approx. 1/8"). |
| The walking belt slows when walked on | a. Use a single-outlet surge suppressor. b. Adjust rear roller bolts to tighten walking belt. |
| The walking belt is off-center or slips when walked on | a. Adjust rear roller bolts to center walking belt. b. Adjust rear roller bolts to tighten walking belt. |
| The upper body arms squeak during use | a. Apply white marine grease to the resistance cone. |
