Manual for SPEEDZONE SPORT - Troubleshooting and error codes + PDF Download
Uploaded: April 8, 2025, 1:50 p.m.
Manual Publish Date: 2007-01-01
Warranty Summary
Specialized cycling computers are warranted for two years against defects in materials and workmanship.
Basic Operations Summary:
- Mode Navigation: Press NEXT or PREV keys to scroll through modes (Speed, Ride Time, Odometer, etc.).
- Setting Time: From clock mode, press and hold PREV, then use NEXT to adjust hours and minutes, confirming each with PREV.
- Setting Wheel Size: Access 'SET BIKE' in settings, choose pre-programmed sizes or manually enter circumference.
- Resetting Computer: Press and hold both PREV and NEXT simultaneously to reset.
Troubleshooting and error codes
| Problem | Solution |
|---|---|
| DISPLAY IS BLANK | Change the battery or reset the computer. |
| DISPLAY SHOWS PARTIAL DIGITS | Reset the computer. |
| SPEED/DISTANCE NOT RECORDING | Check sensor/magnet alignment and distance (max 1/16" or 2mm). |
| ENTIRE SCREEN IS DARK | Move bike to shade if parked in direct sunlight. |
| COMPUTER MOVES ON HANDLEBAR | Tighten tie straps or add sizing straps. |
