Warranty Summary

The product has a one-year limited warranty against defects in materials and workmanship from the date of retail purchase.
Download Manual

Jump Starting a Vehicle:

  • Turn off vehicle ignition and accessories.
  • Ensure Jump-Starter Power Switch is OFF.
  • Connect red clamp to positive battery terminal.
  • Connect black clamp to vehicle chassis (negative ground system) or negative battery terminal (positive ground system).
  • Turn Jump-Starter Power Switch to ON.
  • Crank engine in bursts until it starts.
  • Turn Jump-Starter Power Switch to OFF.
  • Disconnect clamps.

Inflating Tires:

  • Screw SureFit™ nozzle connector onto tire valve stem.
  • Turn on Compressor Power Switch.
  • Check pressure gauge and inflate to desired pressure.
  • Turn off Compressor Power Switch.
  • Disconnect nozzle connector.

Troubleshooting and error codes

Problem Possible Cause
Unit Not Charging
  • Unit functions not turned off.
  • Charger not properly connected to unit and power outlet.
  • DC charging adapter not properly connected.
Unit Fails to Jump-Start
  • Unit's power switch is not in the ON position.
  • Incorrect cable polarity connection.
  • Jump-starter not fully charged.
Portable Compressor will not inflate
  • Compressor Power Switch is not in the ON position.
  • Nozzle connector/adapter not securely attached.
  • Compressor overheated (allow cooling down).
  • Jump-starter not fully charged.
USB Power Port will not power appliance
  • USB Charging Port Power Button is not in the ON position.
  • Appliance incompatible with USB charging port.
  • Jump-starter not fully charged.
12 Volt DC Portable Power Supply will not power appliance
  • Appliance draws more than 5 amps.
  • Jump-starter not fully charged.
LED Area Light does not come on
  • LED Area Light Power Button is not in the ON position.
  • Jump-starter not fully charged.

Troubleshooting and error codes

Problem Possible Cause
Unit Not Charging
  • Unit functions not turned off.
  • Charger not properly connected to unit and power outlet.
  • DC charging adapter not properly connected.
Unit Fails to Jump-Start
  • Unit's power switch is not in the ON position.
  • Incorrect cable polarity connection.
  • Jump-starter not fully charged.
Portable Compressor will not inflate
  • Compressor Power Switch is not in the ON position.
  • Nozzle connector/adapter not securely attached.
  • Compressor overheated (allow cooling down).
  • Jump-starter not fully charged.
USB Power Port will not power appliance
  • USB Charging Port Power Button is not in the ON position.
  • Appliance incompatible with USB charging port.
  • Jump-starter not fully charged.
12 Volt DC Portable Power Supply will not power appliance
  • Appliance draws more than 5 amps.
  • Jump-starter not fully charged.
LED Area Light does not come on
  • LED Area Light Power Button is not in the ON position.
  • Jump-starter not fully charged.
