Manual for TIAGO - Troubleshooting and error codes + PDF Download
Uploaded: April 8, 2025, 1:53 p.m.
Manual Publish Date: 2016-01-01
Warranty Summary
The warranty covers defects in material and workmanship for 24 months or 75,000 km, whichever occurs earlier.
Key Operation:
- Unlock: Press the unlock button once to unlock all doors.
- Lock: Press the lock button once to lock all doors.
- Approach Light: Press the approach light button to turn on lights for 60 seconds.
Doors:
- Lock/Unlock with Key: Use the key in the driver's door.
- Lock from Inside: Use the knob on the door panel.
- Open from Inside: Pull the door opening knob and then lever.
Power Windows:
- Operate using switches on the driver's armrest or individual door switches.
- Operable for 3 minutes after ignition OFF or key removal.
Starting the Engine:
- Insert the key and switch ignition ON.
- Engine starts if the key code matches the vehicle's system.
Troubleshooting and error codes
| Vehicle Condition | Immobilizer Lamp Status | Vehicle State | Meaning / Function of the state |
|---|---|---|---|
| Ignition OFF | Blinking | Locked | Vehicle Immobilized and awaiting electronic key |
| Ignition ON | OFF | Unlocked | Normal condition and ready to start the vehicle |
| Ignition ON | ON | Locked | **Problem with key** (Wrong key used to start vehicle) **Problem with Immobilizer system.** Contact a TATA MOTORS Authorized Service Centre |
| Ignition ON | Blinking | Unlocked | Contact a TATA MOTORS Authorized Service Centre immediately |
Troubleshooting and error codes
| Vehicle Condition | Immobilizer Lamp Status | Vehicle State | Meaning / Function of the state |
|---|---|---|---|
| Ignition OFF | Blinking | Locked | Vehicle Immobilized and awaiting electronic key |
| Ignition ON | OFF | Unlocked | Normal condition and ready to start the vehicle |
| Ignition ON | ON | Locked | **Problem with key** (Wrong key used to start vehicle) **Problem with Immobilizer system.** Contact a TATA MOTORS Authorized Service Centre |
| Ignition ON | Blinking | Unlocked | Contact a TATA MOTORS Authorized Service Centre immediately |
