Brand: VALBERG
Category: Washer
Manual Type:
Language:
Manual for WD8615BW566C - Troubleshooting and error codes + PDF Download
Uploaded: April 8, 2025, 1:52 p.m.
Manual Publish Date: 2021-08-01
Warranty Summary
This VALBERG product is guaranteed for 2 years from purchase date against manufacturing or material defects, excluding issues from incorrect installation, improper use or abnormal wear.
To operate the VALBERG WD8615BW566C Washer Dryer:
1. **Quick Start**: Ensure proper installation and run a Cotton 90°C program without laundry and detergent before first use to clean the appliance. Calibration is recommended for optimal performance.
2. **Before Washing**: Plug in, open tap, load laundry, close door, and add detergent to the appropriate compartment.
3. **Washing**: Power on, select program, choose function or keep default settings, and press Start/Pause to begin.
4. **After Washing**: Wait for buzzer and "End" display. Always check laundry labels and detergent instructions.
1. **Quick Start**: Ensure proper installation and run a Cotton 90°C program without laundry and detergent before first use to clean the appliance. Calibration is recommended for optimal performance.
2. **Before Washing**: Plug in, open tap, load laundry, close door, and add detergent to the appropriate compartment.
3. **Washing**: Power on, select program, choose function or keep default settings, and press Start/Pause to begin.
4. **After Washing**: Wait for buzzer and "End" display. Always check laundry labels and detergent instructions.
Troubleshooting and error codes
| Description | Possible cause | Solution |
|---|---|---|
| Appliance does not start | Door is not closed properly. Clothes are stuck. | Close the door properly and restart. Check the laundry. |
| Door can't be opened | Safety protection is activated. | Disconnect the power and restart. |
| Water leakage | Connections are not tight enough. | Check and fasten the water inlet pipe. Check and clean the outlet hose. |
| Detergent residues in the detergent dispenser | Detergent is damp and/or clotted. | Clean and wipe the detergent dispenser dry. |
| Indicator or display does not work | PC board or harness have connection problems. | Switch off the power and check if the mains plug is connected properly. |
| Abnormal noise | Fixing bolts still in place. Floor is not solid or level. | Check if the fixing bolts have been removed Make sure the appliance is installed on a solid and level floor. |
Troubleshooting and error codes
| Description | Possible cause | Solution |
|---|---|---|
| Appliance does not start | Door is not closed properly. Clothes are stuck. | Close the door properly and restart. Check the laundry. |
| Door can't be opened | Safety protection is activated. | Disconnect the power and restart. |
| Water leakage | Connections are not tight enough. | Check and fasten the water inlet pipe. Check and clean the outlet hose. |
| Detergent residues in the detergent dispenser | Detergent is damp and/or clotted. | Clean and wipe the detergent dispenser dry. |
| Indicator or display does not work | PC board or harness have connection problems. | Switch off the power and check if the mains plug is connected properly. |
| Abnormal noise | Fixing bolts still in place. Floor is not solid or level. | Check if the fixing bolts have been removed Make sure the appliance is installed on a solid and level floor. |
