Warranty Summary
This VALBERG product is guaranteed for 2 years from purchase date against manufacturing or material defects, excluding damage from incorrect installation or improper use.
The basic operation of the VALBERG WF 814 S566C washing machine involves the following steps:
Refer to the manual for detailed instructions on each step and program selection.
- Before Washing: Plug in the machine, open the tap, load laundry, close the door, and add detergent.
- Washing: Power on the machine, select a program, choose functions or keep default settings, and press Start/Pause to begin the wash cycle.
- After Washing: Wait for the buzzer and "End" display to signal the completion of the cycle.
Refer to the manual for detailed instructions on each step and program selection.
Troubleshooting and error codes
| Description | Possible cause | Solution |
|---|---|---|
| Appliance does not start | Door is not closed properly. Clothes are stuck. | Close the door properly and restart. Check the laundry. |
| Door can't be opened | Safety protection is activated. | Disconnect the power and restart. |
| Water leakage | Connections are not tight enough. | Check and fasten the water inlet pipe. Check and clean the outlet hose. |
| Detergent residues in the detergent dispenser | Detergent is damp and/or clotted. | Clean and wipe the detergent dispenser dry. |
| Indicator or display does not work | PC board or harness have connection problems. | Switch off the power and check if the mains plug is connected properly. |
| Abnormal noise | Fixing bolts still in place. Floor is not solid or level. | Check if the fixing bolts have been removed Make sure the appliance is installed on a solid and level floor. |
| E30 | Door is not closed properly | Close the door properly and restart. |
| E10 | Water injecting problem during wash cycle. | Check if the water pressure is high enough. Straighten the water pipe. Clean the inlet valve filter. |
| E21 | Overtime water draining | Check the drain hose for blockages. |
| E12 | Water overflow | Restart the appliance. |
| EXX | Others | Restart the appliance. If the problem persists, please contact customer services. |
Troubleshooting and error codes
| Description | Possible cause | Solution |
|---|---|---|
| Appliance does not start | Door is not closed properly. Clothes are stuck. | Close the door properly and restart. Check the laundry. |
| Door can't be opened | Safety protection is activated. | Disconnect the power and restart. |
| Water leakage | Connections are not tight enough. | Check and fasten the water inlet pipe. Check and clean the outlet hose. |
| Detergent residues in the detergent dispenser | Detergent is damp and/or clotted. | Clean and wipe the detergent dispenser dry. |
| Indicator or display does not work | PC board or harness have connection problems. | Switch off the power and check if the mains plug is connected properly. |
| Abnormal noise | Fixing bolts still in place. Floor is not solid or level. | Check if the fixing bolts have been removed Make sure the appliance is installed on a solid and level floor. |
| E30 | Door is not closed properly | Close the door properly and restart. |
| E10 | Water injecting problem during wash cycle. | Check if the water pressure is high enough. Straighten the water pipe. Clean the inlet valve filter. |
| E21 | Overtime water draining | Check the drain hose for blockages. |
| E12 | Water overflow | Restart the appliance. |
| EXX | Others | Restart the appliance. If the problem persists, please contact customer services. |
