Manual for PRO 4100 - Troubleshooting and error codes + PDF Download
Uploaded: April 8, 2025, 12:49 a.m.
Manual Publish Date: 2002
Warranty Summary
This WEIDER PRO 4100 weight system has a FULL 90 DAY WARRANTY from the date of purchase against defects in material or workmanship.
This manual provides instructions for assembling and using the WEIDER PRO 4100 weight system. It includes steps for frame, arm, cable, and seat assembly. To operate, adjust the weight setting using the weight pin and select appropriate accessories like the lat bar or handles for various exercises. The manual emphasizes safety precautions, exercise guidelines, warming up, working out, cooling down, and maintaining proper exercise form. It also includes cable diagrams, a weight resistance chart, and muscle charts for effective training.
Troubleshooting and error codes
| Problem | Possible Cause | Solution |
|---|---|---|
| Cables are slack before resistance is felt. | Cable stretch after initial use. | Tighten the cables by adjusting pulley positions as described in the 'TIGHTENING THE CABLES' section. |
| Cables bind or do not move smoothly. | Incorrect cable routing or cable traps not positioned correctly. | Verify cable routing using the 'CABLE DIAGRAMS' and ensure cable traps are not obstructing cable movement. |
Troubleshooting and error codes
| Problem | Possible Cause | Solution |
|---|---|---|
| Cables are slack before resistance is felt. | Cable stretch after initial use. | Tighten the cables by adjusting pulley positions as described in the 'TIGHTENING THE CABLES' section. |
| Cables bind or do not move smoothly. | Incorrect cable routing or cable traps not positioned correctly. | Verify cable routing using the 'CABLE DIAGRAMS' and ensure cable traps are not obstructing cable movement. |
