Brand: WESLO
Category: Treadmill
Manual Type:
Language:
Manual for CADENCE G-40 - Troubleshooting and error codes + PDF Download
Uploaded: April 8, 2025, 12:49 a.m.
Manual Publish Date: 2010-01-01
Warranty Summary
WESLO warrants the CADENCE G-40 treadmill against defects with a one-year motor warranty and 90 days for parts and labor.
Basic Operation Summary:
- Power On: Plug in the power cord and insert the key into the console.
- Manual Mode: Select manual mode upon key insertion or by pressing the Program Select button until zeros appear.
- Start Belt: Press the Start button, speed increase button, or a numbered speed button to begin.
- Speed Adjustment: Use speed increase/decrease buttons or numbered buttons to change speed.
- Program Mode: Select a speed program by pressing the Program Select button.
- Stop Belt: Press the Stop button to halt the walking belt.
- Incline Adjustment: Manually adjust the incline legs to the desired level after folding the treadmill.
- Heart Rate Monitoring: Use thumb pulse sensor on foot rails while standing still.
Troubleshooting and error codes
| Problem | Solution |
|---|---|
| The power does not turn on | Ensure power cord is plugged into a surge suppressor and grounded outlet; check key insertion; reset circuit breaker. |
| The power turns off during use | Check circuit breaker; ensure power cord and key are properly connected/inserted. |
| Displays of the console do not function properly | Unplug power, remove hood, check reed switch and magnet alignment/gap. |
| The walking belt slows when walked on | Use a single-outlet surge suppressor; adjust rear roller bolts to loosen walking belt tension. |
| The walking belt is off-center or slips when walked on | Adjust rear roller bolts to center or tighten the walking belt. |
Troubleshooting and error codes
| Problem | Solution |
|---|---|
| The power does not turn on | Ensure power cord is plugged into a surge suppressor and grounded outlet; check key insertion; reset circuit breaker. |
| The power turns off during use | Check circuit breaker; ensure power cord and key are properly connected/inserted. |
| Displays of the console do not function properly | Unplug power, remove hood, check reed switch and magnet alignment/gap. |
| The walking belt slows when walked on | Use a single-outlet surge suppressor; adjust rear roller bolts to loosen walking belt tension. |
| The walking belt is off-center or slips when walked on | Adjust rear roller bolts to center or tighten the walking belt. |
