Brand:
Whirlpool
Category: Ranges
Manual Type:
Language:
Manual for 465 - Troubleshooting and error codes + PDF Download
Uploaded: April 8, 2025, 1:56 p.m.
Manual Publish Date: 1996-01-01
Warranty Summary
Whirlpool 465 Gas Ranges have a one year full warranty, and Electric Ranges with ceramic cooktops have an additional five-year limited warranty on the cooktop.
The Whirlpool 465 range series uses various electronic controls to manage oven functions. Key control types include:
- K.E.T. Single-Knob Control: Features Bake, Broil, Clean settings with indicator lights for Oven On, Heating, and Door Locked/Cleaning.
- EZ-Touch 100: Offers LED display, Custom Broil, Auto Clean, Child Lockout, and Start Prompt.
- EZ-Touch 150: Adds Time-Of-Day Clock, Color-Keyed pads, Electronic Minute Timer and Signal.
- EZ-Touch 200: Includes Vacuum Fluorescent Display, AccuBake, separate Time/Temp displays.
- EZ-Touch 300: Adds Delay Cook and Off functions for advanced scheduling.
Basic operations involve selecting functions like Bake, Broil, or Clean, setting temperature and time using the appropriate control panel, and utilizing features like Child Lockout and Timer as needed.
Troubleshooting and error codes
| Temperature (°F) | Resistance (Ω) |
|---|---|
| 32 ± 1.9 | 1000 ± 4.0 |
| 75 ± 2.5 | 1091 ± 5.3 |
| 250 ± 4.4 | 1453 ± 8.9 |
| 350 ± 5.4 | 1654 ± 10.8 |
| 450 ± 6.9 | 1853 ± 13.5 |
| 550 ± 8.2 | 2047 ± 15.8 |
| 650 ± 8.6 | 2237 ± 18.5 |
| 900 ± 13.6 | 2697 ± 24.4 |
Troubleshooting and error codes
| Temperature (°F) | Resistance (Ω) |
|---|---|
| 32 ± 1.9 | 1000 ± 4.0 |
| 75 ± 2.5 | 1091 ± 5.3 |
| 250 ± 4.4 | 1453 ± 8.9 |
| 350 ± 5.4 | 1654 ± 10.8 |
| 450 ± 6.9 | 1853 ± 13.5 |
| 550 ± 8.2 | 2047 ± 15.8 |
| 650 ± 8.6 | 2237 ± 18.5 |
| 900 ± 13.6 | 2697 ± 24.4 |
