Brand:
Whirlpool
Category: Washers
Manual Type:
Language:
Manual for THIN TWIN - Troubleshooting and error codes + PDF Download
Uploaded: April 8, 2025, 1:45 p.m.
Manual Publish Date: 1994-12-01
Warranty Summary
Whirlpool THIN TWIN washer/dryer has a full one-year warranty for FSP replacement parts and repair labor to correct defects in materials or workmanship from date of purchase.
Washer Operation:
- Add detergent and sorted load.
- Select load size and water temperature.
- Push and turn Cycle Control Knob to desired wash cycle and time.
- Pull out Cycle Control Knob to start.
- Push in Cycle Control Knob to stop.
Dryer Operation:
- Load clothes and close the door.
- Turn Cycle Control Knob to desired drying cycle.
- Push Start Button to begin.
- Open door or turn Cycle Control Knob to OFF to stop.
Troubleshooting and error codes
| Problem | Check the Following |
|---|---|
| Washer will not fill | Are the water supply hoses kinked? Is the Cycle Control Knob set and pulled out? |
| Washer does not spin | Is the lid closed? |
| Washer stops during a cycle | Washer pauses briefly at different times in each cycle. These pauses are normal. |
| Washer fills and drains without running | Is the Cycle Control Knob pointing to a number in the cycle? |
| Washer drains during wash and rinse cycles, or water siphons out | Adjust the drain hose so that it is higher than the water level in the washer. Is the dryer door firmly closed? |
| Dryer will not run | Is the dryer door firmly closed? Did you firmly push the Start Button? Are the controls set in an ON position? |
| Dryer will not heat | Is the cycle in the last few minutes? (There is no heat during that time.) If you have a gas dryer, are the valves open on both the dryer and the supply line? |
| Drying time too long | Is your lint screen clean? (See the "Slow drying" section of the table on page 31 for additional information.) Is your exhaust duct or outside exhaust hood clogged with lint? |
