Manual for YFM250XL(C) - Troubleshooting and error codes + PDF Download
Uploaded: April 8, 2025, 1:45 p.m.
Manual Publish Date: 1998-02
Warranty Summary
No warranty information is present in this service manual.
This service manual provides comprehensive information for maintenance and repair of the YAMAHA YFM250XL(C) Offroad Vehicle. It includes step-by-step instructions for various procedures, from basic periodic checks and adjustments to complex engine overhaul and electrical system troubleshooting. The manual is designed for Yamaha dealers and qualified mechanics, assuming a basic understanding of mechanical principles. Key topics covered include: periodic maintenance schedules, engine removal and disassembly, carburetor service, drive train maintenance, chassis and electrical system inspections and repairs, and troubleshooting guides for common issues.
Troubleshooting and error codes
| Symptoms | Possible causes |
|---|---|
| 1.A pronounced hesitation or “jerky” movement during acceleration, deceleration, or sustained speed. (this must not be confused with engine surging or transmission characteristics.) | A. Bearing damage. |
| B. Improper gear lash. | |
| C. Gear tooth damage. | |
| D. Broken drive shaft. | |
| E. Broken gear teeth. | |
| F. Seizure due to lack of lubrication. | |
| 2.A “rolling rumble” noticeable at low speed; a high-pitched “whine”; a “clank” from a drive train component or area. | G. Small foreign object lodged between moving parts. |
| 3.A locked-up condition of the drive train mechanism, no power transmitted from the engine to the rear wheels. |
Troubleshooting and error codes
| Symptoms | Possible causes |
|---|---|
| 1.A pronounced hesitation or “jerky” movement during acceleration, deceleration, or sustained speed. (this must not be confused with engine surging or transmission characteristics.) | A. Bearing damage. |
| B. Improper gear lash. | |
| C. Gear tooth damage. | |
| D. Broken drive shaft. | |
| E. Broken gear teeth. | |
| F. Seizure due to lack of lubrication. | |
| 2.A “rolling rumble” noticeable at low speed; a high-pitched “whine”; a “clank” from a drive train component or area. | G. Small foreign object lodged between moving parts. |
| 3.A locked-up condition of the drive train mechanism, no power transmitted from the engine to the rear wheels. |
