Manual for 060-3895-8 - Troubleshooting and error codes + PDF Download
Uploaded: April 8, 2025, 1:53 p.m.
Warranty Summary
YARDWORKS CANADA warrants the 060-3895-8 Log Splitter for two years against defects in material or workmanship.
- Bolt support leg, lift by handles, place on stable, flat surface (24-30" high).
- Operate with both hands using ZHB control system (hydraulic lever & pushbutton switch).
- Loosen bleed screw before operation, tighten before moving.
- Do not pressure for > 5 seconds. Rotate hard logs; discard if still hard.
- Set log firmly on retaining plates & work table.
- Break log along grain, not across splitter.
- Avoid splitting 2 logs at once.
Troubleshooting and error codes
| Problem | Cause | Remedy |
|---|---|---|
| The log splitter does not split logs. | The log is not positioned properly. | Refer to the section entitled "operation” for instructions on proper log loading. |
| The log splitter does not split logs. | The size or hardness of the log exceeds the capacity of the machine. | Reduce the size of the log before splitting it on the log splitter. |
| The log splitter does not split logs. | The wedge cutting edge is blunt. | Refer to the section entitled "sharpening the blade” for instructions on how to sharpen the cutting edge |
| The log splitter does not split logs. | There is an oil leak. | Locate the leak, and call the helpline. |
| The log splitter does not split logs. | An unauthorized adjustment was made to the maximum pressure limiting screw-a lower maximum pressure was set. | Call the helpline. |
| The log pusher moves jerkily, makes an unfamiliar noise, or vibrates excessively. | Not enough hydraulic oil and too much air in the hydraulic system. | Check the oil level, and refill the oil if necessary. Call the helpline. |
| Oil leaks around the cylinder ram or from other points. | Air was sealed in the hydraulic system during operation. | Loosen the bleed screw by 3 or 4 rotations before operating the log splitter. |
| Oil leaks around the cylinder ram or from other points. | The bleed screw was not tightened before moving the log splitter. | Tighten the bleed screw before moving the log splitter. |
| Oil leaks around the cylinder ram or from other points. | The oil drain bolt with dipstick is not tight. | Tighten the oil drain bolt with dipstick. |
| Oil leaks around the cylinder ram or from other points. | The hydraulic control valve assembly and/or seal is worn. | Call the helpline. |
Troubleshooting and error codes
| Problem | Cause | Remedy |
|---|---|---|
| The log splitter does not split logs. | The log is not positioned properly. | Refer to the section entitled "operation” for instructions on proper log loading. |
| The log splitter does not split logs. | The size or hardness of the log exceeds the capacity of the machine. | Reduce the size of the log before splitting it on the log splitter. |
| The log splitter does not split logs. | The wedge cutting edge is blunt. | Refer to the section entitled "sharpening the blade” for instructions on how to sharpen the cutting edge |
| The log splitter does not split logs. | There is an oil leak. | Locate the leak, and call the helpline. |
| The log splitter does not split logs. | An unauthorized adjustment was made to the maximum pressure limiting screw-a lower maximum pressure was set. | Call the helpline. |
| The log pusher moves jerkily, makes an unfamiliar noise, or vibrates excessively. | Not enough hydraulic oil and too much air in the hydraulic system. | Check the oil level, and refill the oil if necessary. Call the helpline. |
| Oil leaks around the cylinder ram or from other points. | Air was sealed in the hydraulic system during operation. | Loosen the bleed screw by 3 or 4 rotations before operating the log splitter. |
| Oil leaks around the cylinder ram or from other points. | The bleed screw was not tightened before moving the log splitter. | Tighten the bleed screw before moving the log splitter. |
| Oil leaks around the cylinder ram or from other points. | The oil drain bolt with dipstick is not tight. | Tighten the oil drain bolt with dipstick. |
| Oil leaks around the cylinder ram or from other points. | The hydraulic control valve assembly and/or seal is worn. | Call the helpline. |
